Work we have delivered

A look at the systems we have designed, supplied and commissioned, shown through photos from site.

Water treatment plants

SCADA for Water Treatment Plants (WTP)

Operators run the whole treatment plant from one screen. Every process unit, its inlet, outlet, drain, air and wash valves, the air blowers and the wash-water pumps are shown live, with valve states colour-coded as open, closed or partly open.

Scope of work

Automatic backwash sequencing
Pneumatic valve control for inlet, outlet, drain, air and wash lines
Live clear-water flow rates
Raw-water and clear-water quality on the same screen
Honeywell SCADA stations in the control room

WTP overview on the SCADA station in the control room

Water quality

Online water-quality monitoring

Analyzers on the treatment line measure water quality continuously and send the readings to SCADA, so operators can adjust dosing straight away instead of waiting for lab results.

Scope of work

pH and residual chlorine analyzers
Conductivity and turbidity measurement
Wall-mounted analyzer stations with protected cabling
4–20 mA signals into PLC and SCADA
Calibration and periodic maintenance

pH and chlorine analyzers reading live on the treatment line

Flow converter with pH and conductivity analyzers on site

Pumping stations

Pump station SCADA with motor and pump monitoring

Each pumping unit has its own SCADA overview showing motor, valve and starter status, with scanners watching motor windings and bearings. Any abnormal reading raises an alarm and can trip the pump before damage is done.

Scope of work

Unit overview screens with start, stop and emergency stop
Delivery valve open, close and trip status
Motor winding and bearing RTD temperatures
Vibration readings on motor and pump bearings
Breaker current, voltage and power readings

Pump unit overview on SCADA with valve and motor data

Motor and pump scanner in the control panel

Panel-mounted scanner for a second pumping unit

Flow measurement

Electromagnetic and ultrasonic flow measurement

We supply, install and commission flow meters on water mains and process lines, and use clamp-on ultrasonic meters to check flow without cutting the pipe.

Scope of work

Flanged electromagnetic flow meters on pipelines
Remote and integral flow transmitters with totalisers
Clamp-on ultrasonic transducers for existing pipes
Portable ultrasonic meters for flow verification
Flow signals to PLC, SCADA and telemetry

Electromagnetic flow meter installed on a pipeline

Flow transmitter showing flow rate and total

Clamp-on ultrasonic transducers fixed to a pipe

Control panels

PLC and remote I/O control panels

Panel manufacturing, wiring, installation and commissioning

We manufacture and wire PLC, remote I/O and marshalling panels in our own workshop, then install and commission them on site. Every wire is ferruled and labelled, and signal and power wiring are kept apart for safe, easy maintenance.

Scope of work

Panel manufacturing in our own workshop
Wiring of PLC, digital and analog I/O modules
Remote I/O racks connected over fieldbus
Marshalling panels with terminal blocks for field cables
Installation and cabling on site
Testing and commissioning with the plant running

Remote I/O modules with field wiring in a control panel

Remote telemetry

Remote monitoring with GPRS data loggers

GPRS data loggers read level and flow signals at remote sites and send them over the mobile network, so readings from tanks and pump houses reach a central dashboard without a site visit.

Scope of work

GPRS/GSM data loggers in field panels
Level transmitters on tanks and sumps
Analog and Modbus inputs from field instruments
Readings and alarms sent to a central dashboard
Power supplies and enclosures for outdoor sites

GPRS data logger installed in a field panel

Have a plant or project in mind?

Send us a P&ID, an I/O count or a product list and we'll reply with a scope and quote.
